Distributore ASB-R 4 porte M12x2 segnali M23 collegamento Metal 60 mm
Distributore ASB-R 4 porte M12x2 segnali M23 collegamento Metal 60 mm
Download datasheet
ASBSV-R 4 5-4 – ASBSV-R pluggable actuator/sensor distributor, 4 x M12 ports, 4-poles, without LED operating and function display, two signals per socket, ground connection, M23 connection for the control cable, 12-poles. Plastic, 60 mm
Descrizione
Technnical data
Environmental
Degree of protection IP65 / IP67
Pollution severity 3
Operating temperature range -40°C / +80°C (dragchain and UL max. 60°C)
Materials
Contact CuZn, pre-nickeled and gold-plated
Contact bearer TPU-GF
Housing Zinc die casting
O-ring FKM
Electrical Data
Rated voltage 30 V
Rated current* 4 A per outlet / 12 A max. total; at 40°C
Rated impulse voltage 32 V
Contact resistance ≤5mΩ
Insulation resistance > 10-9 Ω
* only in locked position with its proper counterparts or dust covers
Additional Technical Data
operation display: LED Green
Function display / channel status:
LED Channel A: Yellow
LED Channel B: White
