Technical Data
Environmental
Degree of protection IP 67
Operating temperature range -0°C (+32°F) to +60°C (+140°F)
Mechanical
Weight 535 g
Housing material PUR
Bus system Profibus
ID number 0450 hex
GSD file Lum_0450.gsd
Transmission rate max. 12 MBaud
Address range 1–126 dec
Rotary address switches 1–99 dec
Default address 99 dec
Electronics power supply UL
Rated voltage 24 V DC
Voltage range 19–30 V DC
Power consumption typ. 60 mA
Reverse polarity protection yes
Indication LED green
Input power supply
Voltage range min. (UL – 1.5 V)
Total current of all sensors max. 800 mA
Short circuit-proof yes
Inputs Type 3 acc. to IEC 61131-2
Rated input voltage 24 V DC
Signal state “1” 11–30 V
Signal state “0” -3–5 V
Input current at 24V typ. 6 mA
Channel type N.O. p-switching
Number of digital channels 8
Channel status indicator LED yellow per channel
