Distributore LioN-M Device 8DO (8x M12) M12 Bus connection 7/8” Actuator Supply Plastic 60 mm
Distributore LioN-M Device 8DO (8x M12) M12 Bus connection 7/8” Actuator Supply Plastic 60 mm
Download datasheet
0930 DSL 107 – LioN-M, DeviceNet device with 8 digital outputs (2 A) to connect standard actuators, M12 socket, rotary switches for addressing, M12 bus connection, 7/8“ actuator supply, Plastic, 60 mm
Descrizione
Technical Data
Environmental
Degree of protection IP 67
Operating temperature range -0°C (+32°F) to +60°C (+140°F)
Mechanical
Weight 570 g
Housing material PUR
Bus system DeviceNet
Transmission rate max. 500 kBaud
Autobaud yes
Address range 0–63 dec
Rotary address switches 0–63 dec
Default address 63 dec
Electronics power supply UL
Rated voltage 24 V DC
Voltage range 11–30 V DC
Power consumption max. 80 mA
Reverse polarity protection yes
Indication LED green
Output power supply US
Rated voltage 24 V DC
Voltage range 19–30 V DC
Potential separation present
Reverse polarity protection yes/antiparallel diode
Indication LED green
Outputs Type 2 A acc. to IEC 61131-2
Rated output current 2 A per channel
Short circuit-proof yes
Max. output current 12 A
Overload-proof yes
Number of digital channels 8
Channel type N.O. p-switching
Channel status indicator LED yellow per channel
Diagnostic indication LED red per channel
