M12 maschio-maschio diritto X-coded X-FRNC/LSNH blu Cat 7
M12 maschio-maschio diritto X-coded X-FRNC/LSNH blu Cat 7
Download datasheet
BRSTS 8X-BRSTS 8X-552 – Gigabit Ethernet Cat7 Data Double-Ended Cordset: Male straight X-coded black M12 Railway to male straight X-coded black M12 Railway, shielded, 50 V AC / 60 V DC, 0.5 A; X-FRNC/LSNH blue cable, 8-wires, 4x2x0.25 mm²
CONDIVIDI / SHARE
Descrizione
Shielding: Shielded
Rated Voltage: 60 V
Rated Impulse Voltage: 0.8 kV
Operating Voltage: 50 V AC / 60 V DC
Rated Current*: 0.5 A
Data Transmission: Gigabit Ethernet Cat7
Data Transmission Rate: 10 Gbit/s
Ambient Temperature (Operation)*: – 40 °C – + 85 °C
Protection Degree / IP Rating**: IP65, IP67
